GUARD™
3" 180 degrees Bottom Discharge
€998,71
€825,38 Ex. BTW/VAT
3" 180 Bottom Discharge
Valve+3" II Unify Butterfly Valve+3" BSP dustcap.
Option : Shutting-off device for emergency and fusible link.
Valve+3" II Unify Butterfly Valve+3" BSP dustcap.
Option : Shutting-off device for emergency and fusible link.
Out of Stock
Article code: HDB18002-00
- High quality products
- Dedicated craftsmen
- Extensive range of products
- shipping & returns
Product description
Part No. HDB18002-00
Flange drilled 8x14xPCD178
Outlet 3" BSP
Nominal Pressure 6 bar
Contact Parts in SS 316
Fitted with FEP/Silicon Encapsulated O-Ring
Design Temperature -40 +200 degrees celsius
3" 180 Bottom Discharge 3" 180 Foot
Valve+3" II Unify Butterfly Valve+3" BSP Cap.
Option : Shutting-off device for emergency and fusible link.
