GUARD™
Manlid Assembly 300 mm Low Profile, 4 Points fastening
€768,11
€634,80 Ex. BTW/VAT
300mm Low Profile Inspection Manlid 4 points,
8mm thickness, Stainless Steel swingbolts with
stainless steel handnuts or brass handnuts. Manlid seal sold separately.
Option Different neckring depths, double skin
manlid and swingbolt combinations
8mm thickness, Stainless Steel swingbolts with
stainless steel handnuts or brass handnuts. Manlid seal sold separately.
Option Different neckring depths, double skin
manlid and swingbolt combinations
Out of Stock
Article code: R4343A01-00
- High quality products
- Dedicated craftsmen
- Extensive range of products
- shipping & returns
Product description
300mm Low Profile Inspection Manlid 4 points,
8mm thickness, Stainless steel swingbolts with
stainless steel handnuts or brass handnuts. Manlid seal
sold separately.
Option Different neckring depths, double skin
manlid and swingbolt combinations are available.
Part Number R4343A01-00
Nominal Diameter 300mm
Design Pressure 4 bar(58PSI)
Test Pressure 6 bar(87PSI)
Points 4
Material SS 316L
Design Temperature -40 ~200 C
Temperature range depends on the seal.
Neck ring profiled to suit tank radius.
